Model No.:
LW104S-YLUse:
Used for monitoring residual chlorine concentration in water qualityPower Supply:
Solar Powered + Li-ion BatteryMeasuring Accuracy:
±5%FSLoRaWAN Mode:
OTAA Class A/CShell Material:
ABSCertificates:
CE,ROHSCustomized Support:
OEM,ODMWarranty:
1 YearRemote Calibration of Solar LoRaWAN Water Quality Residual Chlorine Sensor
The solar residual chlorine sensor is an outdoor water quality monitoring device powered by photovoltaics, which detects the residual chlorine content in water in real time through high-precision electrodes. The device has wireless transmission function and can remotely upload data to the monitoring platform.
This sensor is suitable for scenarios such as aquaculture, drinking water treatment, and sewage treatment. It has the characteristics of easy installation, no wiring, and low maintenance, and is an ideal solution for achieving intelligent water quality management.
Water Quality Solar CL Sensor Specification:
Power Supply | Solar Powered + Li-ion Battery | |
Weight | 230g | |
Working Conditions |
Temperature resistance of transmitter components: 0-50 ℃ PH:4-9 Flow rate: 30-60L/h |
|
Measuring Range | 0-2mg/L,0-10mg/L,0-20mg/L | |
Measurement Error | ±5%FS | |
Resolution Ratio |
±0.05mg/L |
|
Temperature measurement range |
0~60℃,Resolution Ratio:0.1℃ |
|
Electrode usage cycle | 12 Months | |
Pressurization | 0.6Mpa | |
Transmitter Line Length |
Default 5m (other lengths can be customized) |
|
Frequency | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4 | |
Mode | OTAA Class A/C | |
Reporting cycle | 30min(Default) | |
Communication Protocol | LoRaWAN | |
Equipment information (Reference) |
AppEUI: 0000000000000001 DevEUI: aaaa202404150001 AppKey: 00001111222233334444555566667777 MAC Version: LoRaWAN 1.0.3 |
Packaging:
Single gross weight: 1.200 KG
Single package size: 37X26X5cm
Product Description:
Customer on-site examples:
Application:
Solar residual chlorine(CL) sensors are widely used in outdoor scenarios such as aquaculture, drinking water disinfection, and sewage treatment to monitor residual chlorine concentration in real-time and ensure water quality safety. With solar power supply and wireless transmission characteristics, it is particularly suitable for long-term monitoring needs in remote areas and environments without mains power.
Certifications
We are best solar water quality residual chlorine(CL) sensor manufacturer and exporter in China with more than 10 years. Our solar water residual chlorine(CL) sensor products are certified with of CE, ROHS.
Production Process:
Why choose us:
